Critical - XR - Power Supply

The Critical XR is equipped with a full color display and a large and easily readable font. The color theme is fully customizable to your own preference.

The display has various settings: voltage, amperes, 'Session Cycle' (%), and 'STL' (Settle). The operation of the XR is contactless, making it easy to cover for hygienic purposes.

The Critical XR can be operated with or without a foot pedal thanks to the option with which the pedal switch is turned off. The XR also has the option to record your session time with one hour of determination.

The XR can register 6 different voltages to facilitate switching between machines or between lining and shading. The biggest difference with previous Critical power supplies is that the XR has an aluminum housing.

The XR also has the possibility for a jump start, which can be used among other things for rotary machines that need an extra boost at the start. The XR comes with a magnetic attachment.

On the Critical XR you can connect one machine, do you prefer to connect two machines at the same time? Then choose the Critical XR-D!

Specifications:

New - Full color TFT display with user selectable color themes and large easy to read fonts.

New - Billet aluminum CNC machined housing

New - Carefully tuned Capacitive touch user interface

New - mount design for more mounting flexibility.

New - Jump start feature and maintained pedal modes now independently assignable to preset/output buttons

New - Genuine high quality Amphenol 1/4” jacks for better power delivery and long life.

Single output on the XR model.

4 amp peak current, 2 amp continuous

Session meter based on user set hourly rate: session mode, run time mode, or hybrid mode (new “Hybrid” billing mode automates user input)

Pedal override button: No need for a foot pedal

Precision regulated set point voltage 0-18vdc

Built in short circuit protection

.1 volt adjustment resolution

Time of day

Voltage presets with 2, 4, or 6 machine memory modes

Non-volatile memory

Universal input 90-240vac 50/60hz

Accepts standard 1/4″ clip cord and foot pedal connections

Volts, Amps, Speed (hz), Duty Cycle (%), and STL

Easily bagged with typical machine or bottle baggies

Additional mounting options available in store

2 year full manufacturer warranty

Included:

XR power supply, magnet mount, US power cord and switching power adapter

2 year full manufacturer warranty

Made in the USA

Watch the video for more info!
